Assignment 5: ESP-NOW Chat Room
While Wi-Fi is great for connecting to the Internet, it requires an Access Point (router) and has overhead due to the connection process. What if you just want multiple ESP32 boards to talk directly to each other?
What is ESP-NOW, actually?
ESP-NOW is a connectionless, low-overhead wireless protocol that Espressif built on top of the Wi-Fi radio. A few things worth knowing as a tinkerer, before we touch any code:
- No router, no handshake. Devices don’t “join a network” the way they do with normal Wi-Fi — there’s no association, no DHCP, no IP address. A board just radios out a small packet, and anyone listening on the same Wi-Fi channel can pick it up. This is also why it’s so fast: there’s barely any protocol overhead between you calling a send function and the bytes going over the air.
- Addressing is by MAC address, not IP. You tell ESP-NOW about a “peer” using its Wi-Fi MAC address (every chip has a unique one). You can also use the special broadcast address
FF:FF:FF:FF:FF:FF, which every nearby board (that is also running ESP-NOW) will receive — effectively a group chat with no server. - Messages are small and unordered. One
esp_now_send()carries at most 250 bytes (ESP_NOW_MAX_DATA_LEN). There is no connection, no retries, and no ordering — if you need those, you build them yourself. For a short line of text between boards, 250 bytes is plenty. - It can be encrypted, but broadcast can’t be. One-to-one peers can use encryption; traffic sent to the broadcast address is always in the clear, since there’s no single peer to share a key with.
- Why would you use it? Anywhere you want several nearby devices to react to each other instantly without any infrastructure: remote controls, synchronized lights, swarms of sensors, or — as in this assignment — a room full of workshop boards exchanging lines you type.
In this assignment we’ll create a chatroom. You will send messages to other devices via the serial monitor - or control other people’s LED!
Start a fresh project this time. ESP-NOW doesn’t need the Wi-Fi provisioning or OTA code from Assignments 3–4:
idf.py create-project esp_now_chat
cd esp_now_chat
idf.py set-target esp32c6
idf.py add-dependency "espressif/led_strip^3.0.3"
idf.py reconfigure
Copy chatroom.c and chatroom.h into your main/ folder.
Add chatroom.c and the components the chat uses:
idf_component_register(SRCS "esp_now_chat.c" "chatroom.c"
INCLUDE_DIRS "."
REQUIRES led_strip esp_wifi esp_event esp_netif nvs_flash)
The new main file (esp_now_chat.c) starts as:
#include <stdio.h>
void app_main(void)
{
}
1. Writing the Code
As before, let’s build main/esp_now_chat.c up instead of pasting it all at once. The chat room calls three functions that you provide here: broadcast, send to one MAC, and remember a MAC as a peer. It never calls esp_now_* itself.
1.1 Skeleton
#include <stdio.h>
// (A) Headers and the broadcast address
// (B) Receive callback: hand the packet to the chat room
// (C) espnow_broadcast, espnow_send, espnow_add_peer
void app_main(void)
{
// (D) Initialize NVS
// (E) Turn the Wi-Fi radio on (station mode, no router)
// (F) Initialize ESP-NOW, register the receive callback, add the broadcast peer
// (G) Start the chat room
}
1.2 Part (A): headers and the broadcast address
#include <stdio.h>
#include <string.h>
#include "esp_event.h"
#include "esp_log.h"
#include "esp_mac.h"
#include "esp_netif.h"
#include "esp_now.h"
#include "esp_wifi.h"
#include "nvs_flash.h"
#include "chatroom.h"
/* Every board names itself: a 4-letter animal picked from its MAC address, then the last two MAC
* bytes in hex, for example "bear83e8". That is exactly 8 lowercase ASCII characters, and the
* hex part makes it unique in the room in practice. */
static const char *const s_animals[] = {
"bear", "wolf", "lynx", "seal", "crab", "frog", "duck", "goat",
"hawk", "mole", "newt", "swan", "toad", "moth", "deer", "orca",
};
static void make_node_name(char name[CHATROOM_NAME_LEN + 1])
{
uint8_t mac[6];
ESP_ERROR_CHECK(esp_read_mac(mac, ESP_MAC_WIFI_STA));
const char *animal = s_animals[(mac[3] ^ mac[4] ^ mac[5]) % (sizeof(s_animals) / sizeof(s_animals[0]))];
snprintf(name, CHATROOM_NAME_LEN + 1, "%s%02x%02x", animal, mac[4], mac[5]);
}
static const char *TAG = "espnow";
static const uint8_t s_broadcast_mac[6] = {0xFF, 0xFF, 0xFF, 0xFF, 0xFF, 0xFF};
Broadcast MAC address is FF:FF:FF:FF:FF:FF in ESP-NOW protocol. Every other ESP-NOW device listens to messages sent for this address.
The chat room needs a name for every board: exactly 8 ASCII characters, unique in the room. Nobody has to pick one, because make_node_name() builds it from the board’s own MAC address: a 4-letter animal plus the last two MAC bytes in hex, like bear83e8 or wolf1f42. Two boards in one room can end up with the same animal, but the hex part makes a clash very unlikely. Your board prints its name when it starts, and list shows the names of the others.
1.3 Part (B): the receive callback
ESP-NOW calls this from the Wi-Fi task whenever a packet arrives. The payload is a raw buffer with a length, not a C string. We don’t interpret it here — chatroom_on_recv does that, and it also reads src_addr, the MAC of whoever sent the packet.
static void on_data_recv(const esp_now_recv_info_t *recv_info, const uint8_t *data, int data_len)
{
if (recv_info == NULL || recv_info->src_addr == NULL) {
return;
}
/* Runs in the Wi-Fi task: hand over fast and return. */
chatroom_on_recv(recv_info->src_addr, data, data_len);
}
1.4 Part (C): send, and add a peer
esp_now_send() hands len bytes to the radio and returns. It does not wait for anyone to receive them — there is no connection to wait on. The same call is a broadcast or a direct message depending only on which MAC you pass.
A direct send works only for a MAC that was registered with esp_now_add_peer(). The chat room does that the first time it hears a new board. channel = 0 means “whatever channel the radio is already on”. Broadcast peers cannot set encrypt.
esp_err_t espnow_broadcast(const uint8_t *data, size_t len)
{
return espnow_send(s_broadcast_mac, data, len);
}
esp_err_t espnow_send(const uint8_t mac[6], const uint8_t *data, size_t len)
{
return esp_now_send(mac, data, len);
}
esp_err_t espnow_add_peer(const uint8_t mac[6])
{
/* Adding twice fails; skip known boards. */
if (esp_now_is_peer_exist(mac)) {
return ESP_OK;
}
esp_now_peer_info_t peer = { 0 };
memcpy(peer.peer_addr, mac, 6);
peer.channel = 0; /* current channel */
peer.encrypt = false; /* no encryption in this workshop */
return esp_now_add_peer(&peer);
}
1.5 Parts (D)–(G): app_main
ESP-NOW needs the Wi-Fi peripheral on, in station mode, even though we never join a router. esp_wifi_start() turns the radio on. NVS comes first, same as in the Wi-Fi assignments, because the Wi-Fi driver stores calibration data there.
The broadcast peer has to be added before the first send, or esp_now_send() to FF:FF:FF:FF:FF:FF fails with “peer not found”. chatroom_start() is the keyboard and the code that prints received lines; everything it transmits goes back through part (C).
void app_main(void)
{
// (D) Initialize NVS
esp_err_t ret = nvs_flash_init();
/* Flash was erased or the layout changed; start NVS fresh. */
if (ret == ESP_ERR_NVS_NO_FREE_PAGES || ret == ESP_ERR_NVS_NEW_VERSION_FOUND) {
ESP_ERROR_CHECK(nvs_flash_erase());
ret = nvs_flash_init();
}
ESP_ERROR_CHECK(ret);
// (E) Turn the Wi-Fi radio on (station mode, no router)
ESP_ERROR_CHECK(esp_netif_init()); /* TCP/IP stack */
ESP_ERROR_CHECK(esp_event_loop_create_default()); /* the loop Wi-Fi posts events to */
wifi_init_config_t cfg = WIFI_INIT_CONFIG_DEFAULT();
ESP_ERROR_CHECK(esp_wifi_init(&cfg));
ESP_ERROR_CHECK(esp_wifi_set_mode(WIFI_MODE_STA)); /* station mode, but we never join a router */
ESP_ERROR_CHECK(esp_wifi_start()); /* radio on; no connection yet */
// (F) Initialize ESP-NOW, register the receive callback, add the broadcast peer
ESP_ERROR_CHECK(esp_now_init());
/* Every packet lands in part (B). */
ESP_ERROR_CHECK(esp_now_register_recv_cb(on_data_recv));
esp_now_peer_info_t broadcast = { 0 };
memcpy(broadcast.peer_addr, s_broadcast_mac, 6);
broadcast.channel = 0;
broadcast.encrypt = false; /* broadcast traffic cannot be encrypted */
ESP_ERROR_CHECK(esp_now_add_peer(&broadcast));
// (G) Start the chat room: keyboard in, chat lines out; sends go through part (C)
char node_name[CHATROOM_NAME_LEN + 1];
make_node_name(node_name);
chatroom_start(node_name);
ESP_LOGI(TAG, "ESP-NOW is up. Type in this monitor.");
}
1.6 Complete code
examples/C6/assignment-05-esp-now has this program in main/esp_now_chat.c, plus the chatroom.c / chatroom.h pair.
2. Build, Flash, and Monitor
idf.py build flash monitor
idf.py monitor is a serial terminal in both directions. Lines the board prints show up here, and keys you press are sent to the board (except Ctrl-], which quits, and Ctrl-T, which opens the monitor menu). The board echoes what you type. A message from someone else can print in the middle of that line; the board still receives only your keystrokes, and Enter sends the line you typed.
Flash a second board (or your neighbour’s). Each board names itself from its MAC address, so there is nothing to edit. In the examples below, yours is bear83e8 and theirs is wolf1f42; look at the line This board is "..." in your own monitor for the real names.
- Type
helloand press Enter. Their monitor printsUser bear83e8: hello. - Type
red(orgreen,blue,white,on,off). Their LED changes, and the monitor printsUser bear83e8 set your LED to 20,0,0(the numbers, not the word). Each level is 0–255. Those words are theCOMMAND_RED(and similar) lines at the top ofchatroom.c; a new word is a new row in that table. - After their board has sent anything, type
wolf1f42:helloorwolf1f42:blueto reach only that board. Until then the monitor says there is no such contact. ESP-NOW keeps 20 peers, and one slot is the broadcast address, so the room remembers 19 names. - Type
listand press Enter. The monitor prints each name this board has heard, with that board’s MAC address.liststays on this board; it is not sent. The list is empty until another board sends something.
A line that is not ASCII is refused. A packet longer than 250 bytes is cut to fit before it is sent. A board does not receive its own broadcast.
Next step
Let’s look at one final feature of the ESP32-C6: The Low-Power core!
